MB2 Teledyne Odom Hydrographic - Multibeam Echosounder

Introducing the MB2 Multibeam Echosounder by Teledyne Odom Hydrographic.

The new MB2 was developed for fast mobilisation on smaller vessels and has been optimised for shallow water survey companies, port and harbour authorities, and dredging companies.

Multibeam Echosounder

The MB2 can be supplied with an optional integrated GNSS aided INS powered by Applanix’ POS MV WaveMaster engine, as well as an integrated real-time SVP sensor to simplify installation and calibration.

The MB2 features a dedicated cylindrical transmit array and broad range of sounding frequencies from 200–460 KHz.

Enhancing the performance of the MB1 by offering a broader coverage and narrower acoustic beam.

The MB2 is able to sound a swath of up to 140° in up to 110m of water depth by using both amplitude and phase bottom detection.

24 bit raw data enables both water column and seabed information to be collected within the controller software.

The Real Time Appliance (RTA) coordinates all of the sensors with accuracy better than 0.1 ms.

Please contact us for more information on the MB2 Multibeam Echosounder by Teledyne Odom Hydrographic.
